The Ellenex PLD2-L Level Sensor is a battery-powered wireless level transmitter that reports liquid levels over LoRaWAN. Built for continuous outdoor and submerged service, it enables maintenance-free monitoring of tanks, wells, reservoirs and waterways for a decade or more.

Key specifications

• Low-power level (and temperature) transmitter for liquid media
• LoRaWAN 1.0.2 Class A; bands AS923, EU868, US902-928 and AU915-928
• Built-in replaceable 3.6 V lithium battery with 10+ years typical service life
• IP68-rated sensor head with UV-protected enclosure for continuous submersion and outdoor use
• High accuracy (typ. ±0.25% span) with stainless-steel wetted parts
• Sampling period configurable over the air via LoRaWAN downlinks (default 4 hours)
• Compact sensor head for wells, tanks and confined installations

It joins any standard LoRaWAN network via OTAA or ABP, so it works with the network server and IoT platform of your choice.
