The Northern Mechatronics NM180100 is an ultra-low-power module that combines a Semtech SX1262 LoRa transceiver with an Ambiq Apollo3 Blue (ARM Cortex-M4F) application processor and Bluetooth 5 LE — a complete long-range wireless compute platform in a 12.8 mm square package. Pre-certified for FCC/IC/CE, it slashes time-to-market for custom LoRaWAN and private-LoRa products.

Key specifications

• Semtech SX1262 LoRa transceiver: 902–928 MHz (NA) / 863–870 MHz (EU), +22 dBm TX, -147.6 dBm sensitivity
• Bluetooth 5 Low Energy radio (2.402–2.480 GHz) for commissioning and short-range links
• Ambiq Apollo3 Blue ARM Cortex-M4F @ 96 MHz; 1 MB flash, 384 KB RAM
• Ultra-low power: 5 µA sleep, 6 µA/MHz processing
• 1.8–3.6 V supply; -40°C to +85°C; 12.8 x 12.8 x 2.4 mm LGA-81
• FCC/IC/CE pre-certified; secure boot, secure key storage, secure OTA

Design your own long-range sensor around a module that already handles the RF hard part.
