The Ellenex DUS3-L Ultrasonic Distance and Level Transmitter is a battery-powered non-contact ultrasonic sensor that measures distance and level over LoRaWAN. With no wetted parts it suits both liquid and solid media — silos, open channels, tanks and bins — and installs above the target with a simple bracket mount.

Key specifications

• Non-contact ultrasonic measurement, 10 m range with 1 mm resolution
• Accuracy ±1% of span (typ.), suitable for liquid and solid media
• LoRaWAN 1.0.2 Class A; bands AS923, EU868, US902-928 and AU915-928
• Built-in replaceable 3.6 V lithium battery; 50,000+ readings typical
• IP65 UV-protected enclosure for harsh outdoor environments
• Sampling period configurable over the air via LoRaWAN downlinks
• OTAA (default) or ABP activation; firmware updatable over the air

It joins any standard LoRaWAN network via OTAA or ABP, so it works with the network server and IoT platform of your choice.
