Laird Connectivity 2.15dBi Antenna FG8240-For 868MHz Gateways
Laird Connectivity · Antennas · EU868

Laird Connectivity 2.15dBi Antenna FG8240-For 868MHz Gateways

SKU ANT-000001-U 470 in stock
$75.00 per unit, wholesale priceAs low as $45.00 per unit at 200+ units
Volume pricing
QuantityUnit price
1 to 23 units $75.00
24 to 47 units $63.75
48 to 95 units $60.00
96 to 199 units $52.50
200 units and above $45.00
The volume price applies automatically in the cart. Quantities of all items in this volume program count together toward the tier.
Request a quote for a larger order

Specifications

The Laird Connectivity 2.15dBi Antenna FG8240 is a unity-gain omnidirectional fiberglass base-station antenna for 868 MHz gateways. Its rugged UV-treated fiberglass radome and N-female connector make it a reliable outdoor antenna for LoRaWAN and other sub-GHz gateway deployments.

Key specs

  • Frequency range 824–896 MHz — covers EU868 LoRaWAN band
  • Unity gain (0 dBd / 2.15 dBi), omnidirectional vertical polarization
  • VSWR ≤ 2:1; 50 Ω nominal impedance; 100 W max power
  • N-female connector; gold-anodized mounting sleeve
  • UV-treated fiberglass radome for long outdoor service life
  • 110° elevation beamwidth (360° azimuth); rated 125 mph wind velocity
  • 100% tested on a network analyzer before shipping

Pairs with Laird lightning arrestors (e.g. LAIL350NN/LABH350NN, sold separately) and FM2SP mounting kits for complete gateway installations.
