Browan MiniHub Pro Gateway, EU868
Browan · Gateways · EU868

Browan MiniHub Pro Gateway, EU868

SKU GTW-000028-868 1,069 in stockMinimum order 30 units
As low as $78.00 per unit at 360+ units · 1 unit $130.00 list price
Volume pricing
QuantityUnit price
30 to 89 units (minimum order) $97.50
90 to 269 units $91.00
270 to 359 units $84.50
360 units and above $78.00
Minimum order 30 units. The volume price applies automatically in the cart. Quantities of all items in this volume program count together toward the tier.
Request a quote for a larger order

Specifications

The Browan Minihub Pro Gateway is an ultra-low-cost 8-channel indoor LoRaWAN gateway with Wi-Fi backhaul. Built on an ESP32 in the same compact wall-plug form factor as The Things Indoor Gateway — but with more processing power and more configurable firmware — it is a popular way to stand up private or community LoRaWAN coverage.

Key specs

  • 8 concurrent LoRa channels, LoRaWAN 1.0.3
  • Supports both Semtech UDP packet forwarder and LoRa Basics Station
  • EU868 band (863–870 MHz) with Listen-Before-Talk
  • Backhaul via Wi-Fi; configured through its own Wi-Fi access point
  • Powered by built-in mains plug or USB-C for flexible placement
  • Built-in omnidirectional antenna for indoor use
  • ESP32-based — more configurable firmware than the basic indoor gateway class

Ready for The Things Network, Loriot, ChirpStack, and other public or private servers on EU868. Note: this standard version does not support AWS IoT Core for LoRaWAN.
