The Laird Connectivity 5.15dBi Antenna FG8243 is a high-gain collinear omnidirectional fiberglass antenna for 868 MHz gateways. Its focused horizontal beam extends LoRaWAN coverage from rooftops and towers while the UV-treated radome stands up to years of outdoor exposure.

Key specifications

• Frequency range 824–896 MHz — covers EU868 LoRaWAN band
• 5.15 dBi collinear gain, omnidirectional vertical polarization
• VSWR ≤ 2:1; 50 Ω nominal impedance; 100 W max power
• N-female connector; cold-sleeve mounting design for flexible installation
• UV-treated fiberglass radome; copper radiating elements
• 60° elevation beamwidth (360° azimuth); rated 125 mph wind velocity
• 100% tested on a network analyzer before shipping

Pairs with Laird lightning arrestors (LABH350NN, sold separately) and FM2 mounting kits for complete gateway installations.
