Northern Mechatronics NM180100-LoRa Bluetooth 5 Low Energy Module
Northern Mechatronics · Components

Northern Mechatronics NM180100-LoRa Bluetooth 5 Low Energy Module

SKU CHP-000001-000 373 in stock
$38.00 per unit, wholesale priceAs low as $22.80 per unit at 200+ units
Volume pricing
QuantityUnit price
1 to 23 units $38.00
24 to 47 units $32.30
48 to 95 units $30.40
96 to 199 units $26.60
200 units and above $22.80
The volume price applies automatically in the cart. Quantities of all items in this volume program count together toward the tier.
Request a quote for a larger order

Specifications

The Northern Mechatronics NM180100 is an ultra-low-power module that combines a Semtech SX1262 LoRa transceiver with an Ambiq Apollo3 Blue (ARM Cortex-M4F) application processor and Bluetooth 5 LE — a complete long-range wireless compute platform in a 12.8 mm square package. Pre-certified for FCC/IC/CE, it slashes time-to-market for custom LoRaWAN and private-LoRa products.

Key specs

  • Semtech SX1262 LoRa transceiver: 902–928 MHz (NA) / 863–870 MHz (EU), +22 dBm TX, -147.6 dBm sensitivity
  • Bluetooth 5 Low Energy radio (2.402–2.480 GHz) for commissioning and short-range links
  • Ambiq Apollo3 Blue ARM Cortex-M4F @ 96 MHz; 1 MB flash, 384 KB RAM
  • Ultra-low power: 5 µA sleep, 6 µA/MHz processing
  • 1.8–3.6 V supply; -40°C to +85°C; 12.8 x 12.8 x 2.4 mm LGA-81
  • FCC/IC/CE pre-certified; secure boot, secure key storage, secure OTA

Design your own long-range sensor around a module that already handles the RF hard part.
